Mathorn TripleBox Charger 20W PD QC

Three-channel capsule charger for camera batteries

The Mathorn TripleBox Charger 20W PD QC is a fast, compact camera battery charger with a closed, capsule design that doubles as a practical battery organiser. It enables simultaneous and independent charging of up to three batteries with a power output of up to 10W. Designed for commercial photographers and passionate travellers documenting their journeys, the new Mathorn TripleBox Charger 20W PD QC ensures you will never have to worry about backup camera power again. Its compact size practically begs for a permanent spot in your camera bag or backpack.

Fast charging with 10W per channel and PD/QC3.0 compatibility

The device features three independent charging slots delivering up to 10W each, managed by a microprocessor that constantly monitors voltage, current, polarity, and temperature. The charger automatically adjusts parameters for each battery individually, protecting the cells from overcharging and overheating.

The charger can be powered by a traditional USB mains adapter or a power bank with a 5V/2A or 9V/2.22A output. When connected to a power source that supports Power Delivery and Quick Charge 2.0/3.0 protocols, the charger reaches its full potential, supplying up to 10W of charging power per battery. This significantly cuts down charging times, getting your camera ready for action much sooner.

Capsule design and organiser functionality

The charger’s unique aesthetic stands out significantly from traditional, flat, open-faced designs. Its modern, streamlined, capsule-like shape allows the device to serve as a highly practical organiser for storing your batteries.

The Mathorn TripleBox Charger 20W PD QC is incredibly simple to operate: just open the cover, insert the batteries, snap the lid shut, and slip it into your bag or backpack. The enclosed design prevents the contents from falling out, scratching, or coming into contact with other gear during transport. Whenever needed, simply connect the charger to a power source to quickly top up the batteries stored inside.

It works perfectly as a stationary device at home or in the studio, acting as a convenient charging dock and organiser, as well as on the road – providing a compact, travel-friendly solution that easily fits into your bag for charging on the move.

Intelligent, colour-coded LED notification system

Each battery slot features a multi-coloured LED indicator that intuitively displays the current stage of the charging process. It guides you from the initial status check upon inserting the batteries (solid white light), through dynamic breathing lights that track progress (breathing red below 80%, breathing blue above 80%), to a solid green light indicating a full charge. Additionally, a dedicated orange LED next to the USB-C port confirms when the 9V PD/QC fast-charging mode is active, giving you complete reassurance that your batteries are being replenished with maximum efficiency.

Key features:

• Three fully independent channels: Charge one, two, or three batteries at the same time, with separate monitoring for maximum charging stability and safety.

• 2-in-1 capsule design: A unique, streamlined form with a secure lid that instantly transforms the charger into a safe travel case and organiser, protecting batteries from falling out or scratching on the go.

• Hassle-free charging anywhere: Safely power the batteries inside the enclosed case directly from a power bank inside your backpack – an ideal setup when moving between shooting locations.

• Fast 20W USB-C power input: Full support for Power Delivery (PD) and Quick Charge (QC2.0/3.0) standards to unleash the maximum performance of the device.

• Impressive 10W power per slot: Dynamic power management delivers up to 10W per slot, drastically reducing the time needed to get back to shooting.

• Intelligent, multi-coloured LED alerts: Intuitive charge status indicators (from white, through breathing red and blue, to solid green) coupled with a separate 9V fast-charging mode indicator.

• Ultra-lightweight build: Weighing just 125g, its compact dimensions make it an unnoticeable addition to your gear during demanding commercial assignments or personal travels.

Currently available models:

• MBC-T200B for Canon LP-E6 / E6NH / E6P batteries

• MBC-T210B for Nikon EN-EL15B / EL15C batteries

• MBC-T220B for Sony NP-FZ100 batteries

Technical specifications:
